The Icom IC-SAT100M Satellite PTT (Push-To-Talk) Mobile Radio offers a reliable and versatile communication solution for users who require seamless connectivity across the globe. This advanced satellite radio utilises the Iridium satellite network, providing complete coverage even in the most remote areas, including both poles.
The IC-SAT100M is designed for various applications, from maritime and aviation to land-based operations, ensuring clear and uninterrupted communication wherever your work takes you.
Key Features:
- Global Communication: Connects to the Iridium satellite network for worldwide coverage, including polar regions.
- Push-To-Talk (PTT) Functionality: Enables instant one-to-many communication with a simple button press.
- Versatile Installation: Designed for both mobile and in-building use, offering flexible installation options.
- High-Quality Audio: 1500mW powerful audio output ensures clear communication in noisy environments.
- Durable Construction: IP67 waterproof rating for the antenna unit with RF unit, and IP54 for the main unit, ensuring reliable performance in challenging conditions.
- Bluetooth Connectivity: Allows for hands-free operation with compatible headsets.
- Integrated GPS: Built-in GPS receiver provides location information.
- Short Data Messaging: Enables quick text communication.
-
Secure Communication: AES 256-bit encryption ensures secure conversations.
Additional Features:
- Voice recording function
- Multiple language display (English, Chinese, French, Japanese, and Spanish)
- Power over Ethernet (PoE) capability for flexible installation
- Compatible with 13.2 and 26.4 V DC vehicle power source
Specifications:
- Frequency Range: 1616 MHz to 1626.5 MHz
- Dimensions:
- Antenna unit with RF unit: 76.8 x 200 x 76.8 mm
- Main unit: 125 x 29 x 156.5 mm
- Microphone: 59.5 x 134.6 x 30.1 mm
- Weight:
- Antenna unit with RF unit: 500g
- Main unit with microphone: 1.2 kg
-
Operating Temperature Range: -30°C to +60°C
Download: Icom IC-SAT100M Brochure
Q&A:
What about communication fees?
Communication fees are typically charged at a flat rate through a monthly plan, and there are no additional call charges.* Communication fees differ, depending on the coverage area and the number of the IC-SAT100/M. * Depending on the country or area, a flat charge plan may not apply, or the service may not be available.
What is a “Talkgroup”?
Using SATELLITE PTT, you can communicate with other IC-SAT100/M radios assigned to the same Talkgroup. The coverage area of the Talkgroup is selectable from five sizes (see the table below).
How do I assign a coverage area?
The coverage area can be split into different coverage regions, using circles, squares, and rectangles. For example, you can assign coverage areas to specific area (see the map below).
Experience uninterrupted global communication with the Icom IC-SAT100M Satellite PTT Mobile Radio. Order now!
